Asus H110M-E LGA1151 Micro ATX Motherboard

SKU: H110M-E

$75.00
RRP $109.00
In Stock
Maximum Order Quantity: 5
Dispatch from warehouse in 24 hours
0
(0 Reviews)

Calculate Shipping




Features

CPU - Intel Socket 1151 for 6th Generation Core i7, i5, i3, Pentium, and Celeron processors
- Supports Intel 14 nm CPUs
- Supports Intel Turbo Boost Technology 2.0 (depends on the CPU type)
Chipset Intel H110
Memory 2 x DIMM, Max. 32 GB, DDR4 2133 MHz Non-ECC, Un-buffered Memory
Supports Intel Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs
* The maximum memory frequency supported varies by processor
Graphics Integrated Graphics Processor
Multi-VGA Output Support: HDMI/VGA ports
- Supports HDMI with a maximum resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
- Supports VGA with a maximum resolution 1920 x 1200 @ 60 Hz
Maximum shared memory of 1,024 MB
Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider
Supports up to 2 displays simultaneously
Expansion Slots 1 x PCIe 3.0/2.0 x1 (x16 mode)
2 x PCIe 2.0 x1
Storage Intel H110 chipset:
4 x SATA III 6 Gb/s ports, gray
Intel Rapid Storage Technology supports
LAN Realtek RTL8111H, 1 x Gigabit LAN controller
Audio Realtek ALC887-VD2 8-Channel High Definition Audio CODEC
- Supports: Jack-detection, Front Panel Jack-retasking
USB Ports Intel H110 Chipset:
4 x USB 3.0/2.0 ports (2 at the back panel, blue, 2 at mid-board)
Intel H110 chipset:
6 x USB 2.0/1.1 ports (4 at the back panel, 2 at mid-board)
Operating System Support Windows 10 (64-bit), 8.1 (64-bit), and 7 (32/64-bit)
Back I/O Ports 1 x PS/2 keyboard (purple)
1 x PS/2 mouse (green)
1 x D-Sub
1 x HDMI
3 x Audio jacks
Internal I/O Ports 1 x COM port connector
1 x CPU Fan connector (1 x 4-pin)
1 x Chassis Fan connector(1 x 4-pin)
1 x S/PDIF out header
1 x 24-pin EATX Power connector
1 x 4-pin ATX 12V Power connector
1 x Front panel audio connector (AAFP)
1 x System panel
1 x Clear CMOS jumper
Manageability WfM 2.0, DMI 3.0, WOL by PME, PXE
Form Factor Micro ATX Form Factor
8.9 x 7.3" / 22.6 x 18.5 cm



SKU H110M-E
Model # H110M-E
Barcode # 00889349276808
Brand Asus
Shipping Weight 0.8000kg
Shipping Width 0.240m
Shipping Height 0.090m
Shipping Length 0.260m
Shipping Cubic 0.005616m3
Unit Of Measure ea
Type store
1 Year Limited Warranty
